• No metal-to-metal moving parts
• No maintenance ever required
• Handle clearly shows ball position
• Silicone-free lubricant on all seals
• Chrome plated brass ball for longer life
• Handle stops on body to avoid stress at stem

• Full port to DIN 3357 for maximum flow

• Hot forged sand blasted, unplated brass body and cap sealed with Loctite® or equivalent threads sealant
• The valve body includes a tapped downstream depressurization venting outlet to direct exhaust air or assemble mufflers for noise control
• Finest brass according to EN 12165 and EN 12164 specifications

• Geomet® carbon steel lockable handle patent n. 7074-B/90 with thick PVC dip coating. Handle coating offers both thermal and electrical protection
• Handle removable with valve in service
• WARNING: do not exceed reasonable temperature and/or electrical load

• Blowout-proof nickel plated brass stem
• Maintenance-free, double FPM O-rings at the stem for maximum safety

• 200 PSI non-shock cold working pressure
• +15°F/ +210°F
• WARNING: freezing of the fluid in the installation may severely damage the valve

• Molybdenum filled PTFE self-lubricating seats with flexible-lip design

• Stainless steel handle (1.4016 / AISI 430)
• Non-locking Geomet® carbon steel lever handle
• ISO 7/1 BSPT taper threads
• EN 10226-1, ISO 228 parallel threads
• Safety pin
• Muffler, hose

• NPT taper ANSI B.1.20.1 female by female threads

• Stainless steel ball (1.4401 / AISI 316)
• Custom design
• T-handle

• GOST-R (Russia)
• RoHS Compliant (EU)
• OSHA Compliant (United States)

NOTE: approvals apply to specific configurations/sizes only.
