Technical Info

  • Anti-static device
  • Locking device
  • Long cycle life
  • Test standard: API 598
  • API 607 4th edition fire safe approval
  • Vacuum service to 29″ Hg
  • Body: ASTM A351 Gr. CF8M
  • Handle in ASTM A536 Gr. 65-45-12
  • WARNING: do not exceed reasonable temperature and/or electrical load
  • Blow-out proof stem design
  • Adjustable stem packing
  • General use: 750 PSI (see chart on reverse)
  • 275 PSI for ASME 150 CF8M (see chart on reverse)
  • Steam rating: 150 PSI WSP
  • -50°F to +475°F
  • WARNING: freezing of the fluid in the installation may severely damage the valve
  • ME-PTFE seal kits: -replaces PTFE, RPTFE and FPA -low deformation under load -low permeation
  • ANSI B16.5, B16.10 and B16.34 full compliance
  • GOST-R (Russia)

  NOTE: approvals apply to specific configurations/sizes only.

*ME-PTFE is Moleculary Enhanced PTFE

Part description Quantity Part Material
Body
1
ASTM A351-CF8M
Cap
1
ASTM A351-CF8M
Ball
1
ASTM A351-CF8M
Stem
1
ASTM A276 Gr.316
Seat
2
ME-PTFE*
Gasket
1
ME-PTFE*
Thrust washer
1
ME-PTFE*
Packing
1
ME-PTFE*
Gland
1
ASTM A351-CF8
Stopper
1
SS304
Torque for actuator sizing in-lb
Pressure-temperature chart

WARNING: This product can expose you to chemicals including lead which is known to the state of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Technical material

Ask for additional information on the whole range of RuB products and consult with your supplier for special applications.

XCE135U
-
4431
