Technical Info
- Suitable for water-works, domestic and agricultural installations
- Non rising stem suitable to most difficult applications
- NPT female by female taper threads
- Hot forged sand blasted brass body
- Low pressure drop
- High performance EPDM stem seal
- Red coated steel hand-wheel
- WARNING: do not exceed reasonable temperature and/or electrical load
- Zinc plated steel top nut
- 150 PSI non-shock cold working pressure
- +14°F to +176°F (-10°C to +80°C)
- WARNING: freezing of the fluid in the installation may severely damage the valve
| Part description | Quantity | Part Material |
|---|---|---|
|
Body
|
1
|
CW617N
|
|
Gate
|
1
|
CB 754S
|
|
Stem
|
1
|
CW614N
|
|
Body cap sealing
|
1
|
Guarnital Fibre
|
|
Cap
|
1
|
CW617N
|
|
Stem ring
|
1
|
CW614N
|
|
Packing gland seal
|
1
|
EPDM90
|
|
Packing gland
|
1
|
CW614N
|
|
Packing gland nut
|
1
|
CW614N
|
|
Red round handle
|
1
|
Steel
|
WARNING: This product can expose you to chemicals including lead which is known to the state of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Technical material
Document
Ask for additional information on the whole range of RuB products and consult with your supplier for special applications.
