Technical Info

  • Dual sealing system allows valve to be operated in either direction making installation easier
  • No metal-to-metal moving parts
  • No maintenance ever required
  • Silicone-free lubricant on all seals
  • Chrome plated brass ball for longer life
  • Each valve is seal tested for maximum safety
  • Handle stops on body to avoid stress at stem
  • Handle/stem clearly shows ball position
  • Hot forged sand blasted brass body
  • Finest brass according to EN 12165 specification
  • Blowout-proof brass stem with FPM O-ring
  • Maintenance-free thanks to FPM O-ring at the stem for maximum safety
  • Reinforced nylon black wedge handle
  • Handle removable with valve in service
  • WARNING: do not exceed reasonable temperature and/or electrical load
  • Pure PTFE self-lubricating seats with flexible-lip design
  • 900 PSI (60 bar) non-shock cold working pressure
  • -4°F to +200°F (-20°C to +90°C)
  • WARNING: freezing of the fluid in the installation may severely damage the valve
  • Male by female threads
  • Nylon wedge handle yellow, red or blue
  • ISO 228 parallel threads
  • NPT taper ANSI B.1.20.1 female by female threads
  • ISO 7/1 BSPT taper threads
  • Other brass alloys or aluminum
  • Additional connection options
  • RoHS Compliant (EU)

NOTE: approvals apply to specific configurations/sizes only.

Part description Quantity Part Material
Nickel plated body (external nickel plated, unplated inside)
1
CW617N
Ball seat
2
PTFE
Chrome plated ball
1
CW617N
O-Ring
1
HNBR
Nickel plated end cap (external nickel plated, unplated inside)
1
CW617
Unplated stem
1
CW617N
O-Ring
1
FPM
Zinc plated screw
1
C10C (EN10263-2)
Black handle
1
Nylon glass filled 30%
Pressure-temperature chart
Pressure drop chart

WARNING: This product can expose you to chemicals including lead which is known to the state of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Technical material

Document

Ask for additional information on the whole range of RuB products and consult with your supplier for special applications.

XCES39N
-
4266
